Redline 2015 Flight BMX Frame-Gray

Original price was: $429.95.Current price is: $95.99.

SKU: redline-3526988136520 Categories: FRAMES, Race Frames Tags: 26380828744out-of-stock, Bmx-frames, Bmx-frames-race, Bmx-race-frames, Discontinued, Discountable, Frames, Redline

Shop with Zero Worries
Online assistance, always just a message away.
Quick responses, top-notch service.
Shop with ease, buy with confidence.

DESCRIPTION:
The R7 frame with result proven geometry has been engineered for the rigors specific to high level BMX racing. Proprietary Redline formed R7 tubing, press-fit BB -86, Redline convertible dropouts and bell shaped seat tube make this the most technically advanced alloy frame on the market.

KEY FEATURES

• Redline Proprietary R7 Formed and Butted Tubing

• Bell Shaped Seat tube

• Integrated Head Tube

• Press-Fit BB-86

• Convertible Dropouts that enable rider to use standard 3/8″ or 15mm through axles

TT: Top Tube | CS: Chain Stay | SA: Seat Angle | HA: Head Angle | H/S: Headset size

SIZE	TT	CS	H/S	HA	SA	SEAT CLAMP	SEAT POST	WEIGHT
MICRO	16″	11-12″	1″(36°/45°)	72°	69°	1″ (25.4mm)	22.2mm	2lbs 2.7oz
MINI	17.5″	12.5-13.5″	1″(36°/45°)	72°	69°	1″ (25.4mm)	22.2mm	2lbs 7.3oz
JUNIOR	18.5″	13-14″	1″(36°/45°)	73°	69°	1″ (25.4mm)	22.2mm	2lbs 8.2oz
EXPERT	19.5″	13.25-14.25″	1-1/8″(45°/45°)	73°	69°	1 1/4″ (31.8mm)	26.8mm	3lbs 3.6oz
EXPERT XL	20″	13.25-14.25″	1-1/8″(45°/45°)	73°	69°	1 1/4″ (31.8mm)	26.8mm	3lbs 4.1oz
PRO	20.5″	13.75-15″	1-1/8″(45°/45°)	74°	70°	1 1/4″ (31.8mm)	26.8mm	3lbs 11.8oz
PRO XL	21″	14.75-16″	1-1/8″(45°/45°)	74°	70°	1 1/4″ (31.8mm)	26.8mm	3lbs 12.4oz
PRO XXL	21.7″	14.75-16″	1-1/8″(45°/45°)	74°	70°	1 1/4″ (31.8mm)	26.8mm	3lbs 12.9oz
PRO XXXL	22.4″	14.75-16″	1-1/8″(45°/45°)	74°	70°	1 1/4″ (31.8mm)	26.8mm	3lbs 12.6oz
JUNIOR 24″	19.8″	14.375-15.375″	1″(36°/45°)	73°	69°	1″ (25.4mm)	22.2mm	2lbs 11.6oz
EXPERT 24″	20.4″	14.375-15.375″	1-1/8″(45°/45°)	73°	69°	1 1/4″ (31.8mm)	26.8mm	3lbs 5.9oz
PRO 24″	21.8″	14.5-16″	1-1/8″(45°/45°)	74°	70°	1 1/4″ (31.8mm)	26.8mm	3lbs 12.9oz
