Haro Annex 24″ BMX Race Bike-Matte Granite RACE BIKES

Rounding out the Annex line is the Annex Pro 24 model. Centered around a 21.75″ top tube cruiser sized frame, the Pro 24 features the same spec found on the 20″ Annex models. With 175mm 3 piece chromoly cranks and full size 24″ 36 spoke alloy wheels, the Pro 24 is strong and versatile for riding at the BMX track or cruising through the neighborhood.

FEATURES

• 6061 series alloy frame with 3D dropouts with integrated chain tensioners
• 100% chromoly fork
• Hi-ten bars and Haro alloy front load stem
• Haro 3-piece chromoly 8-spline race cranks
• Padded one piece seat with built in alloy post
• Kenda Kontact tires
• Promax V-Brake and lever

SPECIFICATIONS

• FRAME: 6061 Series Alloy Frame w/ 3D Dropouts w/ Built In Chain Tensioners
• FORK: Full Cr-Mo 1 1/8″ Threadless w/ Tapered Legs
• COLORS: Matte Black, Matte Granite
• WEIGHT: 23.5lbs
• CRANKS: Haro 3-pc Cr-Mo, 175mm
• BOTTOM BRACKET: Sealed Bearing Euro
• SPROCKET: 40t Alloy
• GEARING: 40/18
• PEDALS: DX Alloy, 9/16″
• CHAIN: KMC 410
• TIRES: Kenda “Kontact” 24 x 1.75″”
• FRONT HUB: Alloy 36h, Loose Ball
• REAR HUB: Alloy Flip-Flop 36h, Loose Ball
• AXLE: 3/8″
• RIMS: 24″ Alloy 36h, Single Wall
• BRAKE: Promax MV-295L Alloy V-Brake
• BRAKE LEVER: Promax XL-378 Alloy Lever
• GRIPS: Micro Knurl Grips
• HANDLE BAR: Hi-Ten, 5.25″ Rise
• STEM: Forged Alloy Top-Load, 45mm Ext.
• HEADSET: Threadless Loose Ball, 1 1/8″
• SEAT: Haro Slim Padded 1-pc
• SEAT POST: Alloy, 27.2mm
• SEAT POST CLAMP: Alloy, 31.8mm

GEOMETRY & SIZING

Size: 24

1. Head Angle: 73°
2. Seat Angle: 71°
3. Top Tube: 21.75 (553 mm)
4. Seat Tube: 10.5 (266.5 mm)
5. Chainstay: 15.6 (397 mm)
6. BB Height: 12 (305 mm)
7. Stand Over: 23.6 (599 mm)
